UV curing machine - dual lamp desktop flat UV curing machine

UV curing machineIntroduction to the Device

The newly designed UV-300 UV curing machine is specifically designed for fast drying of UV ink after printing. Not only is it fast to dry and fix, but it is also easy to operate and maintain.

1. The brightness of the UV lamp is controlled at a high level, suitable for different types of printing materials with photopolymerization

2. UV tube and UV system overheating protection system make the tube life longer

3. Non variable speed motor control allows for arbitrary adjustment of the machine's photopolymerization speed

4. Imported UV systems and UV lamps from the United States make the light curing effect more stable

Technical parameters:

Delivery bandwidth: 300mm

Product height: 120mm (adjustable)

Fastest transfer speed: 4000Pcs/Hour

Power requirement: AC220C 3PHASE 50Hz

Rated power: 4.5KW

Uv system: 2KW=2 sets

Uv lamp length: 320mm

Uv lamp wavelength: 365nm

Machine size: 1300 * 550 * 1050mm

Machine weight: 40kg

UV curing machine is suitable for the curing and drying process of all photosensitive materials, and has the characteristics of adjustable light waves and fast curing speed. It is an indispensable production equipment for precision printing, spraying, LCD components and other fields.

Performance characteristics of UV curing machine:

1. Install 2 sets of UV light fixation systems with stable light intensity (each set of UV is independently controlled), and turn on the number of lamps according to the production speed;

2. The conveyor belt is made of Teflon (high temperature resistant), finely crafted, and runs smoothly;

3. Adopting special aluminum magnesium alloy lampshade, spotlight design, energy-saving and efficient;

4. The working current of the UV lamp can be monitored through an external indicator, effectively grasping the working status of the UV system;

5. The conveyor belt has stepless speed regulation, which can be adjusted according to the production situation;

6. The printing and drying speed is 5000-8000 sheets per hour (split);

7. Equipped with a reasonable heat dissipation system to prevent product deformation caused by excessive temperature in the working chamber;

8. Set up a light intensity regulator that is suitable for different types of products.
