Tianjin Tiantuo TNJ704-1 (G4) tractor
Tianjin Tiantuo TNJ704-1 (G4) tractor
Product details
Technical parameters of Tianjin Tiantuo TNJ704-1 tractor
| Serial Number | Basic configuration | unit | Basic parameters |
| 1 | model | / | TNJ704-1(G4) |
| 2 | Dimensions (length x width x height) | mm | 3575 × 1480 × 2480 (top of anti rollover frame) |
| 3 | Minimum usage quality | kg | 2025 |
| 4 | type | / | 4 × 4 four-wheel drive |
| 5 | engine | / | YN38NDE4 |
| 6 | rated power | kW | 51.5 |
| 7 | rated speed | r/min | 2300 |
| 8 | Transmission type | / | Mechanical plane composition |
| 9 | Steering system type | / | Full hydraulic steering |
| 10 | Tire model (front/rear) | / | 7.50-16/11.2-28 |
| 11 | wheelbase | mm | 1860 |
| 12 | front track | mm | 940, 1000, 1100, 1140 |
| 13 | Rear wheelbase | mm | 920-1150 |
| 14 | Power output speed | r/min | 540/720 |
| 15 | Form of hydraulic suspension system | / | Split type |
| 16 | Suspension device form | / | Rear three-point suspension |
| 17 | Maximum counterweight (front/rear) | kg | 72/60 |
| 18 | Number of hydraulic output groups | group | 2 groups |
| 19 | Optional equipment | / | driving cab |
