Oil immersed AC test transformer YDJ
Oil immersed power frequency AC test transformer YDJ oil immersed power frequency AC test transformer is particularly suitable for conducting insulati
Product details
1、 Product Overview:
The YDJ (G) oil immersed lightweight AC high voltage test transformer is a new type of product produced based on the YDJ (G) series test transformers and the national standard JB/T 9641-1999, which has been extensively improved on the basis of similar products according to the "Test Transformer" standard.
The iron core of YDJ oil immersed AC test transformer is a single-phase core type, which is made of high-quality cold-rolled oriented silicon steel sheets stacked together and fastened using steel as clamps. The high-voltage coil is a cylindrical multi-layer tower made of high-quality polyester enameled wire and high voltage insulation material wound around it. The low-voltage coil is located outside, and the instrument coil is an independent winding. Generally, it is 100V. The test transformer with an octagonal shell of 10kVA or more is equipped with a movable iron wheel. It has the characteristics of light weight, small size, easy mobility, and superior performance.
YDJ oil immersed AC test transformer has the characteristics of small size, light weight, compact structure, complete functions, strong universality, and easy use. Specially suitable for conducting insulation strength tests on various high-voltage electrical equipment, electrical components, and insulation materials under power frequency or DC high voltage in power systems, industrial and mining enterprises, scientific research departments, etc. It is an essential and important equipment in high-voltage testing.
Product alias: Power frequency withstand voltage test, also known as AC withstand voltage resonance device, power frequency AC test transformer, series resonance transformer, series resonance test equipment, AC withstand voltage test equipment, cable withstand voltage test equipment, GIS AC withstand voltage test device, frequency modulation series resonance withstand voltage test device, frequency modulation series resonance test device, generator AC withstand voltage test device, cross-linked cable AC withstand voltage test device, frequency modulation series resonance test transformer, power frequency resonance withstand voltage test equipment.
2、 Product features:
1. The oil immersed test transformer has a compact structure, stability, durability, and low price.
2. Simple and intuitive wiring, easy to use
3. Good insulation reliability and beautiful appearance
Product Parameters
Model parameter correspondence table
|
Model number |
capacity (KVA) |
high voltage （KV） |
high-voltage current （mA)） |
Low voltage input |
transformation ratio (Height/Instrument) |
Temperature rise ℃ (30 minutes) |
|
|
Voltage (V) |
Current (A) |
||||||
|
1.5/50 |
1.5 |
50 |
30 |
200 |
7.5 |
500 |
10 |
|
3/50 |
3 |
50 |
60 |
200 |
15 |
500 |
10 |
|
5/50 |
5 |
50 |
100 |
200 |
25 |
500 |
10 |
|
10/50 |
10 |
50 |
200 |
200 |
50 |
500 |
10 |
|
20/50 |
20 |
50 |
400 |
400 |
50 |
500 |
10 |
|
30/50 |
30 |
50 |
600 |
400 |
75 |
500 |
10 |
|
50/50 |
50 |
50 |
1000 |
400 |
125 |
500 |
10 |
|
5/100 |
5 |
100 |
50 |
200 |
25 |
1000 |
10 |
|
10/100 |
10 |
100 |
100 |
200 |
50 |
1000 |
10 |
|
20/100 |
20 |
100 |
200 |
400 |
50 |
1000 |
10 |
|
300/200 |
300 |
200 |
1500 |
400 |
750 |
2000 |
10 |
|
50/300 |
50 |
300 |
170 |
400 |
125 |
3000 |
10 |
|
Note: Customization can be customized according to user needs. |
|||||||
Product Brochure
Product accessories
|
name |
quantity |
unit |
|
Instruction Manual |
1 |
this |
|
Inspection Report |
1 |
copy |
|
Certificate of Conformity |
1 |
Zhang |
Product Atlas
-
No partial discharge test transformer test site
-
Cascade test transformer
-
Intelligent type of power frequency test transformer
-
High voltage test transformer test transformer
Product Certificate
