High and low temperature test chamber environment simulation aging chamber temperature and humidity calibration chamber It is a testing equipment used in fields such as aviation, automotive, home appliances, and scientific research to test and determine the parameter performance of electrical, electronic, and other products and materials after undergoing high temperature, low temperature, and alternating humidity tests.

1. Temperature range -20~+150 ℃
2. Humidity range: 20~98%
3. Cooling rate 1-1.2 ℃/min (non-linear under no load)
4. Heating rate 2-3 ℃/min (non-linear under no load)
5. Temperature stability ± 0.5 ℃
6. Humidity stability ± 2.5% RH
7. Temperature deviation ± 2.0 ℃
8. Humidity deviation ± 2.5% RH
9. Temperature fluctuation range -20 ℃ to+150 ℃ (any temperature point can be set)

1. Material composition 3.2.1 Outer wall material: Cold rolled steel plate with electrostatic double-sided spray coating
2. Inner wall material: SUS304 stainless steel plate
3. Insulation material: 100mm glass wool insulation layer
4. Load bearing capacity of structural strength test box: ≤ 100kg (uniform load)
5. The main door is fully open, with a single wing box door and a lock.
Two silicone rubber sealing strips on the door frame, anti condensation electric heating device for low-temperature room door frames
6. There is one multi-layer observation window on the observation window door, and the observation window on the low-temperature chamber door is coated and heated to prevent condensation and frosting
7. The condensate outlet has outlet holes for studio condensate and unit condensate
8. There is an overflow hole located at the bottom of the overflow hole box to facilitate the outflow of condensed water.
9. Low voltage lighting fixtures are installed at the top of the lighting studio, controlled by a control screen switch
10. One lead hole with a diameter of 50MM is standard. Satisfy the testing of samples with power on and signal testing

High and low temperature test chamber environment simulation aging chamber temperature and humidity calibration chamber It is a testing equipment used in aviation, automotive, home appliances, scientific research and other fields to test and determine the parameters and performance of electrical, electronic and other products and materials after high temperature, low temperature, alternating humidity or constant temperature environment changes. The experimental data can be copied through a USB flash drive, and the computer does not need to install any software to directly open the experimental curve or Excel document. Thoroughly designed structure; Water and electricity separation design, temperature uniformity. Stratospheric design, ± 1.0 ℃, to prevent dripping from the top of the test chamber. Alarm history display and troubleshooting methods.
