Economic high-performance frequency converter

·Power range: 0.1~15KW
·Advanced magnetic flux vector control, 200% torque output at 0.5Hz
·Expand PID, flexible PWM
·Built in Modbus RTU protocol
·Stop improving accuracy
·Add option card FR-A7NC, which can support CC Link communication
·Add option card FR-A7NL, which can support LONWorks communication
·Add option card FR-A7ND, which can support Deveice Net communication
·Add option card FR-A7NP, which can support Profibus DP communication

FR-E740 series, 3-phase 380V 50HZ level, lightweight universal type (150% 60 second overload capacity)

model	output power	Rated current surface price	（RMB)
FR-E740-0.4K-CHT	0.4KW	1.6A	1,880
FR-E740-0.75K-CHT	0.75KW	2.6A	1,960
FR-E740-1.5K-CHT	1.5KW	4.0A	2,270
FR-E740-2.2K-CHT	2.2KW	6.0A	2,790
FR-E740-3.7K-CHT	3.7KW	9.5A	3,270
FR-E740-5.5K-CHT	5.5KW	12A	4,640
FR-E740-7.5K-CHT	7.5KW	17A	4,960
FR-E740-11K-CHT	11KW	23A	5,550
FR-E740-15K-CHT	15KW	30A	7,170

FR-E720S series, single-phase 220V 50HZ level, lightweight universal type (150% 60 second overload capacity)

model	output power	Rated current surface price	（RMB)
FR-E720S-0.4K-CHT	0.4KW	2.5A	2,200
FR-E720S-0.75K-CHT	0.75KW	4.0A	2,360
FR-E720S-1.5K-CHT	1.5KW	7.0A	2,510
FR-E720S-2.2K-CHT	2.2KW	10A	3,270

FR-E720 series, 3-phase 220V 50HZ level, lightweight universal type (150% 60 second overload capacity)

model	output power	Rated current surface price	（RMB)
FR-E720-0.4K	0.4KW	3A	3,080
FR-E720-0.75K	0.75KW	5A	3,310
FR-E720-1.5K	1.5KW	8A	3,520
FR-E720-2.2K	2.2KW	11A	4,580
FR-E720-3.7K	3.7KW	17.5A	5,530
FR-E720-5.5K	5.5KW	24A	8,690
FR-E720-7.5K	7.5KW	33A	10,100
FR-E720-11K	11KW	47A	13,500
FR-E720-15K	15KW	60A	15,700
