Color touch screen portable conductivity meter
The portable conductivity meter with color touch screen can choose electrode constant, temperature compensation type, temperature compensation coeffic
Product details
Bante20Color touch screen portable conductivity meterBased on the Android operating system, it has conductivity TDS、 Salinity, resistivity, and conductivity ash measurement mode, measurement accuracy: 0.5% F.S.
Color touch screen portable conductivity meterFunctional characteristics
High precision intelligent conductivity meter equipped with platinum conductivity electrodes.
Calibration from 1 to 3 points, automatic identification of conductivity standard solution.
• Optional electrode constant, temperature compensation type, temperature compensation coefficient, pure water compensation coefficient, reference temperature and TDS conversion coefficient.
Automatic temperature compensation ensures accurate measurement across the entire range.
Automatic endpoint locking, retaining stable readings for easy browsing and recording.
Read at regular intervals and send measurement data to memory or printer.
Limit alarm, automatically warning whether the measured value exceeds the set range.
Calibration expiration reminder, reminding users to calibrate the instrument regularly.
Calibration report, displaying date, time, calibration point, and conductivity cell coefficient.
Password protection to prevent unauthorized calibration and settings.
Multi parameter measurement, capable of connecting S10 pH and S60 dissolved oxygen meters and displaying measurement values simultaneously.
Reset function, automatically restore the instrument to factory default settings.
Supports multiple versions of connectivity including Bluetooth and WIFI across the entire network.
GPS positioning.
Real time measurement data.
5.5-inch high-definition IPS touch screen.
Technical Parameter
model |
Bante50 |
conductivity | |
measuring range |
0.01~20.00, 200.0, 2000µS/cm, 20.00, 200.0mS/cm |
display resolution |
0.001, 0.01, 0.1, 1,automatic |
measurement accuracy |
±0.5% F.S. |
calibrated point |
1to3drop |
Calibration solution |
84µS/1413µS/12.88mS/111.8mS |
TDS | |
measuring range |
0~200.0g/L |
display resolution |
0.01, 0.1, 1,automatic |
measurement accuracy |
±1% F.S. |
TDSconversion coefficient |
0.01to1.00 (default0.5) |
salinity | |
measuring range(practical salinity) |
0.00~42.00psu |
measuring range(seawater) |
0.00~80.00ppt |
measuring range(%) |
0.00~8.00% |
display resolution |
0.01 |
measurement accuracy |
±1% F.S. |
resistivity | |
measuring range |
0.00~10.00MΩ |
display resolution |
0.01, 0.1, 1,automatic |
measurement accuracy |
±1% F.S. |
Conductivity ash content | |
measuring range |
0~100% |
display resolution |
0.01, 0.1, 1,automatic |
measurement accuracy |
±1% F.S. |
Measurement mode |
Refined sugar or crude sugar |
OTHERS | |
Temperature compensation range |
0~100°C/32~212°F,automatic |
Temperature compensation coefficient |
linear(0.0~10.0%/°C)/Nonlinear/USP/EP |
Pure water compensation |
contain |
reference temperature |
20/25°C |
Conductivity cell constant |
K=1 |
stability condition |
fast/standard/high-precision |
Measurement mode |
Continuous or automatic endpoint locking |
Timed interval reading |
10/30/60/300Second or off |
Calibration expiration reminder |
1to99Day or Close |
tall/Low limit alarm |
optional |
data transmission |
Memory or printer |
Password protection |
6Digit number |
processorCPU |
Mt6580 |
framework |
ARM Cortex-A7GHz1.3GHz |
system |
Android8.1.0 |
storage |
8GB ROM+1GB RAM |
display |
5.5HD,1280×720 IPS |
Camera |
500megapixel+autofocus |
WIFI |
2.4Ghz,supportIEEE802.11 a/b/g/n |
communication model |
Support China Unicom3G/2G,move2G |
Bluetooth |
Supports Bluetooth3.0/4.0, supportBLE |
microphone |
support |
speaker |
support |
key |
Power button (lock screen button)+Volume increase/Reduce key |
External Interface |
BNC, 3.5mmMicrophone plug;Type-C USB; SupportOTGfunction |
charger |
5V/2A |
barcode recognition |
Rear camera scanning, supports1D/2DBarcode scanning and reading |
SIM |
support |
TF/SDblock |
≤64G |
PASMblock |
support |
connectivity |
WIFI、GPS、Bluetooth、GSM |
Power source |
Detachable lithium battery3.7V/5000mAh |
External dimensions |
211×87×60.5mm |
Instrument weight |
500G(including battery) |
